Syn 2 Bay 3.5″ TWR NAS Drive (DS225+)

Home>Network Attached Storage>Syn 2 Bay 3.5″ TWR NAS Drive (DS225+)
Syn 2 Bay 3.5" TWR NAS Drive (DS225+)
Syn 2 Bay 3.5" TWR NAS Drive (DS225+) - Image 2
Syn 2 Bay 3.5" TWR NAS Drive (DS225+) - Image 3

Syn 2 Bay 3.5″ TWR NAS Drive (DS225+)

$813 inc. GST

In stock (can be backordered)

SKU: DS225+ Category:

Description

Features

The Synology DiskStation DS225+ is a compact 2-bay NAS solution designed to centralize data management, offering a comprehensive suite of tools through Synology DiskStation Manager DSM for managing, sharing, and protecting files and photos, backing up devices and data, and serving as the core of a smart surveillance system. 3 Year Warranty extendable to 5 years with EW201 ( additional purchase)

  • Powerful 2-bay all-round storage solution for small businesses
  • 2GB DDR4 onboard memory expandable up to 6GB with DDR4 non-ECC SO-DIMM 4 GB (D4NS014G)
  • Organize and stream your music, video, and photo collections across all your devices
  • Maximum IP camera: 25 (total of 750 FPS at 720p, H.264) (includes two free camera licenses; additional cameras require the purchasing of additional licenses)
  • Back up critical data and reduce your Recovery Time Objective (RTO) with Snapshot Replication
  • Model supports Active Backup-Office 365
Hardware Specifications
CPU
CPU ModelIntel Celeron J4125
 CPU Quantity1
 CPU Core4
 CPU Architecture64-bit
 CPU Frequency2.0 (base) / 2.7 (turbo) GHz
 Hardware Encryption Engineyes
Memory
System Memory2 GB DDR4 non-ECC
 Total Memory Slots1
 Maximum Memory Capacity6 GB (2 GB + 4 GB)
 Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier’s product life cycle status.
  • Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability.
  • Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
Storage
Drive Bays2
 Drive Type (See all supported drives)
  • 3.5″ SATA HDD
  • 2.5″ SATA SSD
 Hot Swappable Drive*yes
 Notes

Synology only guarantees full functionality, reliability, and performance for compatible drives.

Please consult our compatibility list before purchasing hard drives. For more details, please refer to this article.

External Ports
RJ-45 1GbE LAN Port1
 RJ-45 2.5GbE LAN Port1
 USB 3.2 Gen 1 Port2
 USB Copyyes
 NotesMTU value of 1GbE LAN port has a limit of 1500.
Appearance
Size (Height x Width x Depth)165 mm x 108 mm x 232.2 mm
 Weight1.3 kg
Others
System Fan92 mm x 92 mm x 1 pcs
 Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
 Brightness Adjustable Front LED Indicatorsyes
 Power Recoveryyes
 Noise Level*19.6 dB(A)
 Scheduled Power On / Offyes
 Wake on LAN / WANyes
 Power Supply Unit / Adapter60 watts
 AC Input Power Voltage100V to 240V AC
 Power Frequency50/60 Hz, Single Phase
 Power Consumption*16.98 watts (Access)
6.08 watts (HDD Hibernation)
 British Thermal Unit57.90 BTU/hr (Access)
20.73 BTU/hr (HDD Hibernation)
 Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state.
  • Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device.
  • Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature0°C to 40°C (32°F to 104°F)
 Storage Temperature-20°C to 60°C (-5°F to 140°F)
 Operating Humidity8% to 80% RH
 Storage Humidity5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
  • BIS
Warranty
3-year hardware warranty, extendable to 5 years with EW201
 Notes
  • The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)
  • EW201/EW202 is only available in Asia, Africa, and Oceania. Refer to the Extended Warranty website for details on supported countries/regions. (Learn more)
Environment
RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
Optional Accessories
Notes:
  1. Model specifications are subject to change without prior notice.
  2. The figures are based on Synology internal testing. Each performance test is done individually. No other services or applications are processed at the same time.
  3. The actual performance may be lower than lab testing figure due to differences in server configuration, deployment, and the number of active operations.
  4. If usage requirements exceed the specifications above, please contact our regional partners for professional advice.
