Description

Model Number MCS-S400-KN5N-S00 (Steel), MCS-S400-KG5N-S00 (TG) Color(s) Black Materials – Body Steel, Plastic, Sound Absorbing Material Dimensions (L x W x H) 418 x 210 x 408mm (Incl. Protrusions), 403.5 x 210 x 400mm (Excl. Protrusions) Volume 33.9L (excl. Protrusions) Motherboard Support Mini-ITX, Micro-ATX Expansion Slots 4 5.25″ Drive Bays 1 3.5″ Drive Bays 4 2.5″ Drive Bays 4 I/O Panel – USB Ports 2x USB 3.2 Gen 1 (formerly USB 3.0) I/O Panel – Audio In / Out 1x 3.5mm Headset Jack (Audio+Mic) I/O Panel – SD Card Reader Supports SD & MMC Cards Pre-installed Fans – Front 1x 120mm (PWM 800-1400 RPM) Pre-installed Fans – Rear 1x 120mm (PWM 800-1400 RPM) Fan Support – Front 2x 120/140mm Fan Support – Top 1x 120mm, 1x 140mm / 2x 120mm, 2x 140mm (remove ODD cage) Fan Support – Rear 1x 120mm Radiator Support – Front 120 / 140 / 240 / 280mm (remove & reinstall ODD bracket to mount 280mm radiator, may interfere with HDD mounted below ODD bracket) Radiator Support – Top 120 / 240mm* (*240mm requires removal of ODD cage) Radiator Support – Rear 120mm Clearance – CPU Cooler Steel: 167mm, TG: 166mm Clearance – PSU 325mm (w/o front radiator & drive cage), 140mm (HDD cage in backmost position) Clearance – GFX 319mm Cable Routing 20mm Dust Filters Front, Top, Bottom Power Supply Support Bottom Mount, ATX PS2 Size Mini Tower Series Silencio Series
